22-gallon fresh water tank capacity with visual water levels
24-gallon used water capacity
Syphon port for pump out
Fits inside most portable restrooms for easy transport
1408 pumps of water
Model BRA1-2000 is available for warm water washes
Description
Values
Height
62 in / 157 cm
Width
26.5 in / 67 cm
Depth
21.5 in / 54 cm
Weight Empty
70 lb / 32 kg
Weight Full
254 lb / 115.2 kg
Fresh Water Capacity
22 gal / 83 ltr
Grey Water Capacity
24 gal / 91 ltr
Paper Towel Dispenser
250 towels per pack. 1000 towels per wash station.
(Four packs of single-fold towels Georgia Pacific 23504)
Soap Dispensers (2)
Single Dispenser Capacity
30 fl. oz. / 887 ml
Total Dispenser Capacity
60 fl. oz. / 1774 ml
Number of Single Dispenses
1408 / 1408
Pump Capacity (per stroke)
2 fl. oz. / 59.14 ml
Note: In certain geographical areas of the USA, a warning decal, "Not for Drinking or Cooking" is required. This sink is supplied with PC-000782 Warning Decal, which is located directly below the faucet. It is suggested that this decal be replaced if it becomes damaged or worn out.
All materials, including resin, pigments and additives used to make the plastic components as well as the plumbing components that come in contact with the fresh water supply are U.S. Government Food & Drug Administration (FDA) food grade compliant materials
All dimensions are subject to change due to environmental factors.
